6. Connect the cables that exit the central han-
dlebar (left side) with the connectors of the ca-
ble light blue female faston cable
and 5x2 pin connector.
7. Ret the central handlebar, following the
procedure described in this paragraph in re-
verse order.
RUN PERSONAL-UPGRADE VISIOWEB-UNITY 2.0
Assembly instructions- Rev. 1.1
e-mail: support@technogym.com
Page 18
