Technogym Skillmill - Display (Connect Version)

1500 ± 50
100 ± 10 130(REF)
71.70 ± 0.5
10 ± 0.5
18.9 ± 0.4
50 ± 0.5
33.25 ± 0.5
Figure 7 - measurements in mm
3.1.2 DISPLAY (CONNECT VERSION)
Display with the following characteristics:
• WI-FI technology
• Display backlighting
• Keyboard backlighting
• Heart key backlighting
It receives a 5V power supply from the Low Kit. It can be powered using the mini USB port installed,
or by connecting a PC or specic USB power supply unit.
The display is equipped with a Wi-Fi board.
From the SW High Kit BA_1.43 version onwards: the default display is always ON, even if the
exercise has been completed. This means the LEDs can always be kept switched on, even when
no-one is using the equipment.
Skillmill
Technical Service Guide - Rev. 3.5
Page 28
