3. OPERATING PRINCIPLE
3.1 ELECTRONIC COMPONENTS
3.1.1 VOLTAGE CONVERTER (POWER SUPPLY UNIT)
The voltage converter receives the high voltage and transforms it into low voltage (5V). It can
supply a maximum current of 2A to power all the equipment electronics (display, angle sensor,
RPM sensor and NFC).
DC output
voltage
Minimum
current
Maximum
current
5V 0A 2A
Table 21 - technical characteristics
It's equipped with 4 dierent sockets, on the basis of the necessary standard.
In the CONNECT version, it's connected to the Low Kit, through which it powers all the equipment's
electronic components. In the CORDLESS version, it's used to recharge the baery when necessary.
Skillmill:
