CU0889: 5V JACK cable
(Baery/5V jack)
Baery
(jack with cast ca-
ble)
Signal Colour 5V jack
1 +5V DC Red 1
2 GND Black 2
Table 19
CU0890: Low Kit / baery
Low Kit Signal Colour Baery
- - - -
2 +5V DC Red 1
3 GND Black 4
- - - -
Table 20
