CU0866: Cable A - Low Kit / CPU board
(Low Kit / patch connector)
Patch connector Signal Colour Low Kit
1 +5V DC Black 1
2 UI_TX Brown 2
3 UI_RX White 3
4 LKIT_RPM sensor Blue 4
5 GND_Power Grey 5
- N.C. (GND) -
- N.C. (AUX_TX) -
- N.C. (AUX_RX) -
Table 16
CU0883: Cable B - Low Kit / CPU board
(Patch connector / patch connector)
Patch connector Signal Colour Patch connector
1 +5V DC Yellow 1
2 UI_TX Brown 2
3 UI_RX White 3
4 RPM Green 4
5 GND Grey 5
Table 17
CU0884: Cable B - TGS / NFC
(Patch connector / patch connector)
Patch connector Signal Colour Patch connector
1 NFC_Power-ON Yellow 1
2 rs232_RFID_RX Brown 2
3 rs232_RFID_TX White 3
4 DGND Green 4
Table 18
Skillmill:
Technical Service Guide - Rev. 3.5
