Technogym Skillmill - 2.9 CABLES

2.9 CABLES
The colour of the cables may change: in particular, refer to the Pin Out.
2.9.2 CU CABLES
CU0853: Cable A - Low Kit / CPU board
(CPU board / patch connector)
CPU board Signal Colour Patch connector
1 +5V DC Yellow 1
2 UI_TX Brown 2
3 UI_RX White 3
4 LKIT_RPM sensor Green 4
5 GND_Power Grey 5
- - -
Table 9
CU0854: Cable A - TGS / NFC
(NFC / patch connector)
NFC board Signal Colour Patch connector
1 +3.3V DC NFC Yellow 1
2 rs232_RFID_RX Brown 2
3 rs232_RFID_TX White 3
- - - -
- - - -
- - - -
- - - -
8 DGND Green 4
Table 10
CU0855: 5V power supply cable
(Power supply/ Low Kit)
Low Kit board Signal Colour 5V input JACK
1 +5V DC Red 1
2 +5V DC Red 1
3 GND Black 2
4 GND Black 2
- - - -
Table 11
Skillmill:
Technical Service Guide - Rev. 3.5
