CU0863: Cable A - Angle sensor
(Patch connector / angle sensor)
Patch connector Signal Colour Angle sensor
1 +3.3V DC Brown 1
2 Angle White 2
3 GND Green 3
Table 12
CU0867: Cable B - Angle sensor
(Patch connector / Low Kit)
Patch connector Signal Colour Low Kit
1 +3.3V DC Brown 1
2 Angle White 2
3 GND Green 3
Table 13
CU0864: RPM sensor cable
(Low Kit / patch connector)
Low Kit Signal Colour Patch connector
1 RPM signal Brown Faston
2 GND Black grommet
Table 14
CU0865: Cable C: TGS / NFC
(Patch connector / CPU board)
Patch connector Signal Colour CPU board
1 NFC_Power-ON Yellow 1
2 rs232_RFID_RX Brown 2
3 rs232_RFID_TX White 3
4 DGND Green 4
Table 15
