Installation: Commissioning
- Cello 6 Wizard: Meter settings
Step 8 - Meter settings
- The initial "Meter settings" page is now displayed although the content will depend on
the options selected at the "Installation: Commissioning - Cello 6 Wizard: Channel
configuration" section of this manual as follows:
- For example where the here the "Ch1" and "Tamper" options were selected:
- For example where only the "Ch1" option was selected:
- For example where both the "Ch1" and "Ch2" options were selected:
