UPS EXA PLUS 1000 – 1500 - 2000 11 User’s manual
8 Technical Characteristics
UPS EXA PLUS Model 1000
1500
2000
Power 1000 VA (700 W) 1500 VA (1050 W) 2000 VA (1400 W)
Technology Line Interactive with Stabilizer
Nominal Input Voltage Single-phase 230 Vac
Input Voltage Range +20% / -25%
Input/Output Frequency 50/60 Hz (automatic selection)
Input Frequency Range +/- 5%
Nominal Output Voltage Single-phase 230 Vac
Output Voltage Regulation
(Normal mode)
Through AVR (Automatic Voltage Regulation)
Output Voltage Regulation
(Battery mode)
+/- 5%
Output Inverter Waveform Sinewave
Accepted Overload < 130%
Certifications
CE
Standards: Low Voltage (Safety) Directive 2014/35/EU –
EMC (Electro-Magnetic Compatibility) Directive 2014/30/EU
Battery Type Lead acid, sealed, free maintenance
Number of batteries 1 2
Nominal Battery Voltage 12 Vdc 24 Vdc
Battery Specifications 12 Vdc – 7,2 Ah – 6 cells 12 Vdc – 9 Ah – 6 cells
Backup Time (typical) 8 min 10 min
Battery Charge Time (typical) 4 hours
Hot Swap Battery Included
Audible Noise (at 1 meter)
<12 dBA 1m (line mode)
<40 dBA 1m (when the
fan is working)
<12 dBA 1m (line mode)
<45 dBA 1m (when the fan is working)
Cooling Fan cooling (only with AVR active or in Battery mode)
Environmental Operative Specification
Temperature: 0-40 °C - Humidity 0-95% (without condensation)
Altitude: max 3.000 mt
Computer Interface
1 USB port
UPS Management Software
Software TECNOMANAGER,
downloadable free of charge from www.tecnoware.com
SNMP Interface
No
Telephone and Modem protection
RJ11/RJ45 plugs included
Output sockets 4 UPS Output sockets (IEC type) + 4 ONLY FILTERED Output sockets (IEC type)
Dimension (W x H x D) 9,9 x 28 x 28,8 cm 9,9 x 28 x 41 cm
Net Weight 7,4 Kg 11,8 Kg 13,1 Kg
Technical data may change without prior notice
(*) Connect the printers to the ONLY FILTERED Output sockets
