59
Parameter
Signal
Name & Function Default Unit
Setting
Range
Control
Mode
Chapter
Digital input control method selection.
★Hn510
Select digital input (6 pins) control method by
external terminal or communication. Convert Binary
code to Hex code for setting this parameter. DI and
binary bits table as below.
Binary code representation：
￫” 0 “ Digital input control by external terminal.
￫” 1 “ Digital input control by communication.
Set H0000 for Hn510 represent DI-1,DI-3, DI-6 are
controlled by external terminal and set H0003F
represent all terminal is controlled by
communication.
The corresponding binary code is :[10 0101]
convert
to Hex code is : [H 0025]for entering parameter.
For the setting Bit0 (DI-1) is control by
communication and Bit1 (DI-2) is control by external
terminal ….etc
H0000 X
H0000
│
H003F
(HEX)
ALL 5-6-1
Setting digital input status in communication
mode
★Hn511
Change Hn511 Hex code for setting digital input
status of communication control mode; Setting
method refer Hn510.
Binary code representation：
“0” : digital input contact OFF
“1” : digital input contact ON
Set H0000 for Hn510 represent H0000 are
controlled by external terminal and set H0003F
represent all terminal is controlled by
communication.
P.S.)This parameter should co-operate with
Hn510.
H0000 X
H0000
│
H003F
(HEX)
ALL 5-6-1
