58
Parameter
Signal
Name & Function Default Unit
Setting
Range
Control
Mode
Chapter
DI-2 Programmable Digital input Selection
★Hn502
Please refer to Hn501
002 X
001
│
11C
ALL 5-6-1
DI-3 Programmable Digital input Selection
★Hn503
Please refer to Hn501
003 X
001
│
11C
ALL 5-6-1
DI-4 Programmable Digital input Selection
★Hn504
Please refer to Hn501
104 X
001
│
11C
ALL 5-6-1
DI-5 Programmable Digital input Selection
★Hn505
Please refer to Hn501
105 X
001
│
11C
ALL 5-6-1
DI-6 Programmable Digital input Selection
★Hn506
Please refer to Hn501
006 X
001
│
11C
ALL 5-6-1
DO-1 Programmable Digital Output Selection
Setting Explanation
007 X
001
│
11C
ALL 5-6-1
Signal Functions
01
RDY
Servo Ready
02
ALM
Alarm
03
ZS
Zero Speed
04
BI
Brake Signal
05
INS
In Speed
06
INP
In Position
07
HOME
HOME
★Hn507.0
★
Hn507.1
08
INT
In Torque
01 X
01
│
08
DO-1 Digital Output Logic State.
Setting Explanation
0
Close, when the output is activated.
★Hn507.2
1
Open, when the output is activated.
0 X
0
│
1
ALL 5-6-1
DO-2 Programmable Digital Output Selection
★Hn508
Please refer to Hn507
002 X
001
│
108
ALL 5-6-1
DO-3 Programmable Digital Output Selection
★Hn509
Please refer to Hn507
003 X
001
│
108
ALL 5-6-1
★New setting will become effective after re-cycling the power.
Warning! If any of programmable Inputs of DO-1 ~ DO-3 are set for the same type of function
then the logic state selection ( NO or NC selection) for these inputs must be the same type.
Otherwise an Alarm will be displayed. AL-07 (Abnormal DI/DO programming).
