FIRMWARE RESET FUNCTION
This device works on advanced and
stable firmware to enhance users’
enjoyment. In the event that a sudden
firmware glitch does occur, press the
[RESET] button to return to normal
operation; stored stations will not be lost
when resetting the firmware.
The [RESET] button is located behind
the [TUNING] knob :
1) Gently pull the [TUNING] knob from the device.
2) Use a pointy object to press the [RESET] button.
3) Put the [TUNING] knob back into position.
Issues that might occur due to a sudden firmware glitch:
- Device cannot be powered on.
- Display does not turn on or behaves erratically.
- Buttons do not respond when pressed.
29
SPECIFICATIONS
FREQUENCY RANGE AND TUNING STEPS
LW: 100 ~ 519 kHz, at 1 kHz / 9 kHz tuning step
MW: 520 ~ 1710 kHz, at 1 kHz / 10 kHz tuning step (North & South America)
522 ~ 1620 kHz, at 1 kHz / 9 kHz tuning step
(Asia, Africa, EU & Oceania regions)
SW: 1711 ~ 29999 kHz, at 1 kHz / 5 kHz tuning step
(While using SSB mode reception for the above bands,
the tuning step is at 10Hz / 1 kHz)
FM: 64 ~ 108 MHz (Russia, the Caucasus, the Caspian Sea and parts of the Black
Sea region)
76 ~ 108 MHz (Japan)
87 ~ 108 MHz (China and Europe)
88 ~ 108 MHz (USA)
(FM frequency tuning step is 10 kHz / 100 kHz)
