Ф3.5mm stereo earphones jack
23
Low-impedance
FM / SW antenna socket
High-impedance
AM antenna socket
26
Telescopic antenna (for short wave and FM)
22
Antenna port (Red)
Ground (black)
27
28
Battery compartment
2 pieces 18650 rechargeable lithium battery
DC (5V) USB Charging socket
INT ANT./EXT ANT. switch
- “INT ANT.” position: When using the telescopic antenna.
- “EXT ANT.” position: When using an external antenna.
LOCATION OF CONTROLS ( SIDE AND BACK OF THE RADIO )
( Use for LW / MW / SW )
DX / LOCAL switch
DX position: For long-distance reception,
and when the received signal is weak.
- LOCAL position: For local reception,
and when the received signal is strong.
-
24
20
Line out jack
Connect the radio to
an external audio amplifier using an audio cable.
21
25
2
