Setup Instructions for BoomPilot
®
98-05243 R0
GPS IS REQUIRED
GPS is used to congure GPS Type and GPS Port.
NOTE: These settings are required for auto steering and tilt sensor operation, as well as proper implement
operation.
1. Press CONFIGURATION side tab .
2. Press GPS .
3. Select from:
►GPS Type – select GPS source transmissions
►GPS Port – sets (D)GPS COM port
►GPS Status – displays information for TeeJet Customer Service use on GGA/VTG (Data Rates),
Number of Satellites, HDOP, PRN, GGA Quality, GPS Receiver and Receiver Version.
4. Press RETURN arrow or CONFIGURATION side tab to return to the main Conguration screen.
Figure 1-4: Tilt
Conguration
Vehicle
Implement
AutoSteer
Tilt
Lightbar
GPS
Video
Cong->GPS
GPS Status
GPS Port
GPS Type
Information
Internal
GPS/DGPS
