the beginning of the current phase.
Con Compressor ON time with faulty probe: (0÷ 255 min) time during which the compressor is active
in case of faulty thermostat probe. With COn=0 compressor is always OFF
COF Compressor OFF time with faulty probe: (0÷255 min) time during which the compressor is off in
case of faulty thermostat probe. With COF=0 compressor is always active
PROBES
rPO Thermostat probe calibration (-12,0 ÷ 12,0; res. 0,1 °C /1°F)
EPP Evaporator probe presence (not present in the XB350C): (no / YES) no: not present (timed
defrost); YES: present (end defrost )
EPO Evaporator probe calibration (not present in the XB350C): (-12,0 ÷ 12,0; res. 0,1 °C /1°F)
i1P Insert probe 1 presence (no / YES) no: not present; YES: present.
i1o Insert probe 1 calibration (-12,0 ÷ 12,0; res. 0,1 °C /1°F)
i2P Insert probe 2 presence (no / YES) no: not present; YES: present.
i2o Insert probe 2 calibration (-12,0 ÷ 12,0; res. 0,1 °C /1°F)
i3P Insert probe 3 presence (no / YES) no: not present; YES: present.
i3o Insert probe 3 calibration (-12,0 ÷ 12,0; res. 0,1 °C /1°F)
rEM End cycle probe selection. (iPt, rP). It sets which probe stops teh the cycle, thermostat probe or
insert probe.
iPt = insert probe;
rPt =thermostat probe
NOTE, with rEM = rPt when the cycles are done by temperature, the rSi values are used as
stop of the cycle.
DISPLAY AND MEASUREMENT UNIT
CF Temperature measurement unit: °C =Celsius; °F =Fahrenheit
rES Resolution (for °C): in: integer; de: with decimal point
Lod Upper display visualization: select which probe is shown by the upper display:
rP = Thermostat probe
EP = Evaporator probe
rEd Remote display, X-REP, visualization: select which probe is displayed by the X-REP:
rP = Thermostat probe; EP = Evaporator probe; tiM: cycle count down; i1P = insert probe 1; i2P =
insert probe 2; i3P = insert probe 3.
DIGITAL INPUTS
d1P: Door switch input polarity (25-26): (OP÷CL)select if the digital input is activated by opening or
closing the contact. OP= opening; CL=closing
odc Compressor and fan status when open door:
no = normal;
Fan = Fan OFF;
CPr = Compressor(s) OFF;
F_C = Compressor(s) and fan OFF.
doA Open door alarm delay:(0÷254min,nu) delay between the detection of the open door condition and
its
