Tekno RC EB48 - Bag H: Front Suspension Assembly; Front Suspension Components; Front Suspension Assembly Steps

TKR5020
TKR5017
TKR5079
TKR5059
TKR5049
TKR5036
TKR5017
TKR5021
TKR5021
TKR1333
TKR1327TKR1327
TKR1525
TKR1443
TKR5049
Pivot Ball Sway Bar
x2
TKR5079
Stabilizer Ball
x2
TKR1443
M4x10mm Button Head Screw
x2
TKR1525
M3x14mm Cap Head Screw
x2
TKR1327
M3x16mm Flat Head Screw
TKR1333
M3x40mm Flat Head Screw
x2
x2
TKR1525
Stock Position
Stock Position
*TKR5049A
(Option)
Step
H-1
Step
H-2
Bag H
Front Suspension
(overview)
12
TKR1333
TKR1443
TKR1327
