Field or control Description
Label Enter a label for the bus. The default label is the selected bus type.
T
o enter label text, double-tap the field and enter label using the virtual keyboard, or tap the field and
enter text from an attached keyboard.
Bus Type Set to LIN.
Source Set the signal source from available analog or digital channels.
Threshold Set the threshold level to define a logic high level.
Polarity Select the polarity (Normal or Inverted) to match the LIN bus being acquired.
LIN Standard Select the standard to match the LIN bus being acquired.
Bit rate Sets the bit rate.
To enter a custom bit rate, select Custom and enter the custom bit rate in the Custom Rate input box.
Include Parity Bits with ID Set to Yes to include parity bits with the ID.
Sample Point Sets the sample point from 5% to 95% of the position within the bit period or the unit interval.
Display Format Sets the waveform view to show just the decoded bus information, or the decoded bus and the logical
views of each constituent signal.
Decode Format Sets the decode format used to display the bus information. Formats are Hex, Binary, and Mixed.
Mixed displays the Frame Id and parity in decimal, and everything else is displayed in hexadecimal
format.
Other bus types
Serial bus types, such as CAN, LIN, Ethernet, and so on, are available as purchasable options. Once purchased and installed, the new bus
types are shown in the Bus T
ype menu. The serial bus options also add corresponding bus trigger capabilities to the Trigger menu.
Use the following links to access information on specific Bus configuration menus.
Parallel Bus configuration menu on page 127
I2C serial bus configuration menu on page 123
SPI serial bus configuration menu on page 131
RS-232 serial bus menu on page 129
CAN serial bus configuration menu on page 120
LIN serial bus configuration menu on page 124
FlexRay serial bus configuration menu on page 122
Audio serial bus configuration menu on page 118
USB serial bus configuration menu on page 132
MIL-STD-1553 serial bus menu on page 126
ARINC429 serial bus menu on page 117
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 125
