Field or control Description
Word Sets the audio word channel for which to search.
Only available when Mark On = Data and the Audio bus is I2S, RJ, or LJ .
Mark When Sets the mark when condition for the specified data pattern.
When set to Inside Range
or Outside Range, fields are displayed to set a high and low boundary
pattern for the specified search range.
Only available when Mark On = Data and the Audio bus is TDM .
Data Low, Data High
Sets the boundary data conditions when testing for in-range or out of range conditions.
Available when Mark When is set to Inside Range or Outside Range.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change.
Use the B knob to change the value of the digit(s).
Or double-tap the field and use the virtual keypad to enter the data. See Binary, decimal, hex, and
octal virtual keypads on page 228.
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings. If the trigger settings are not
valid in Search, this control is either not available or grayed out.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
CAN serial bus search configuration menu
Use the CAN Search configuration menu to define conditions to search for and mark on a CAN bus waveform.
Note: Requires option SRAUT
O.
Field or control Description
Display Enables or disables displaying search marks on this search.
Source Select the CAN bus that you want to search.
Mark On Select the type of information for which to search.
Frame Type Sets the frame type for which to search.
BRS Bit Sets the BRS bit state for which to search.
Only available when Mark On = FD BRS Bits.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 139
