ARINC429 serial bus trigger settings panel
Use the ARINC429 bus menu (optional) to set up and decode a ARINC429 avionics network serial data bus waveform
Note: Requires option SRAERO.
Field or control Description
Source Select the ARINC429 bus on which you want to trigger
.
Trigger On Select the type of information on which to trigger.
Error Type Sets the error condition on which to trigger.
Available when Trigger On = Error.
Trigger When Sets the condition on which to trigger.
Available when Trigger On = Label.
Label Sets the label pattern on which to trigger.
Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Label & Data or Trigger When = any condition except Inside Range or
Outside Range.
Label Low Sets the low value of the label pattern range on which to trigger.
Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger When = Inside Range or Outside Range.
Label High Sets the high value of the label pattern range on which to trigger.
Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger When = Inside Range or Outside Range.
SSM Sets to trigger when the specified Sign/Status Matrix (SSM) bit condition occurs.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Available when Trigger On = Data and the Data Format is set to Data (19 bits) or SDI+Data (21
bits).
SDI Sets to trigger when the specified Source/Destination Identifier (SDI) bit condition occurs.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Available when Trigger On = Data and the Data Format is set to Data (19 bits).
Trigger When Data Sets the condition on which to trigger.
Available when Trigger On = Label & Data.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 200
