Field or control Description
Low Address Sets the low address value for which to search.
T
ap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark When RT Address = Inside Range or Outside Range.
High Address Sets the high address value for which to search.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark When RT Address = Inside Range or Outside Range.
Subaddress/Mode Sets the subaddress or mode value for which to search.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Command.
Word Count/Mode Code Sets the word count or mode count value for which to search.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Command.
Status Word Bits Sets the status word pattern for which to search.
Tap the field and use the A and B knobs to select and change the values. Selecting a bit shows a short
description of that bit's function.
Only available when Mark On = Command.
Table continued…
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 147
