Tektronix AWG70001A Installation And Safety Instructions

Product upgrades
AWG70001A ugrades Description
AWG701AUP Opt. 01 Increases the waveform record length to 16 Gsamples
AWG701AUP Opt. 03 Adds sequencing
AWG701AUP Opt. SSD Provides an additional (or replacement) preprogrammed solid state drive
AWG701AUP Opt. AC Adds a single-ended AC coupled output connector with additional amplification and attenuation
AWG70002A upgrades Description
AWG702AUP Opt. 01 Increases the waveform record length to 8 GSamples for each channel
AWG702AUP Opt. 03 Adds sequencing
AWG702AUP Opt. 0816 Increases the sampling rate from 8 GS/s to 16 GS/s
AWG702AUP Opt. 0825 Increases the sampling rate from 8 GS/s to 25 GS/s
AWG702AUP Opt. 1625 Increases the sampling rate from 16 GS/s to 25 GS/s
AWG702AUP Opt. SSD Provides an additional (or replacement) preprogrammed solid state drive
ReplaceableParts
Item Tektronix part number
Rear panel foot (four per instrument) 348-2037-xx
Screw 211-1459-xx
Front bottom flip-foot (two per instrument) 348-1950-xx
Screw 211-1459-xx
Foot cushion 348-1947-xx
Rear bottom foot (two per instrument) 348-1948-xx
Screw 211-1459-xx
Foot cushion 348-1947-xx
Handle (two per instrument) 367-0570-xx
Foam 348-2067-xx
Screw (two per handle) 211-1459-xx
Install the instrument
AWG70000A Series Installation and Safety Instructions 3
