Analog AC output (AWG70001A with Option AC)
Output connector Aeroflex/Weinschel Planar Crown Universal Connector System with SMA female adapter
Number of analog AC outputs AWG70001A: 1
Type of outputs single ended
Output impedance 50 Ω
Amplitude
Range (for a CW signal at
specified frequencies in each
path)
Filter path Description
No filter 25 dBm to -70 dBm at 1 GHz
18 dBm to -77 dBm at 13 GHz
Low pass 25 dBm to -70 dBm at 1 GHz
Band pass (10 GHz to 14.5 GHz) 18 dBm to -77 dBm at 11 GHz
Band pass (13 GHz to 18 GHz) 20 dBm to -90 dBm at 14 GHz
18 dBm to -90 dBm at 18 GHz
Accuracy (at calibration
frequency)
Filter path Description
No filter ±0.5 dB at 1 GHz, ambient 16 °C to 26 °C
±1.5 dB at 1 GHz, ambient 0 °C to 50 °C
Low pass ±0.5 dB at 1 GHz, ambient 16 °C to 26 °C
±1.5 dB at 1 GHz, ambient 0 °C to 50 °C
Band pass (10 GHz to 14.5 GHz) ±1.5 dB at 11 GHz, ambient 16 °C to 26 °C
±3.0 dB at 11 GHz, ambient 0 °C to 50 °C
Band pass (13 GHz to 18 GHz) ±1.5 dB at 14 GHz, ambient 16 °C to 26 °C
±3.5 dB at 14 GHz, ambient 0 °C to 50 °C
Resolution 0.01 dB
Specifications
AWG70000A Series Installation and Safety Instructions 27
