Auxillary outputs
10 MHz reference out
Connector SMA (rear panel)
Output impedance 50 Ω, AC coupled
Amplitude +4 dBm ±2 dBm
Frequency 10 MHz ±(1 ppm + aging)
Synchronization clock output
Frequency 1/80 of the clock output
Amplitude 1.0 V ±150 mV
p-p
into 50 Ω
Connector SMA (rear panel)
Output impedance 50 Ω, AC coupled
External clock output
Connector SMA (rear-panel)
Output impedance 50 Ω AC coupled
Frequency range 6.25 GHz to 12.5 GHz
Output amplitude +5 dBm to +10 dBm
Auxiliary inputs
External Clock in
Connector SMA (rear panel)
Input impedance 50 Ω, AC coupled
Frequency range 6.25 GHz to 12.5 GHz
Input amplitude 0 dBm to +10 dBm
Trigger
Number of inputs 2 (A and B)
Slope/Polarity Positive or negative selectable
Connector SMA (rear panel)
Input impedance 50 Ω or 1 kΩ selectable
Input voltage range 50 Ω: <5 V
rms
1 kΩ: ±10 V
Threshold range -5.0 V to 5.0 V
Threshold resolution 0.1 V
Reference in
Fixed frequency range 10 MHz, ±10 ppm
Variable frequency range 35 MHz to 240 MHz
Acceptable frequency drift while the instrument is operating is ±0.1 %.
Specifications
AWG70000A Series Installation and Safety Instructions 29
