Marker outputs
Output connector SMA (front panel)
Number of outputs
AWG70001A 2
AWG70002A 4
Type of outputs (+) and (-) complementary
ON/OFF control Independent control for each marker
Impedance 50 Ω
Output voltage Independent control for each marker
Amplitude range 0.5 V
p-p
to 1.4 V
p-p
into 50 Ω
Amplitude resolution 10 mV
Offset range 1.4 V – (amplitude ÷ 2) to –1.4 V + (amplitude ÷ 2) into 50 Ω
Offset resolution 10 mV
DC accuracy ±(10% of |output high or low setting| + 50 mV) into 50 Ω
External termination voltage range –2.8 V to +2.8 V
Variable delay control Independent control for each marker
Range 0 to 100 ps
Resolution 1 ps
Flag outputs
Output connector SMB (rear panel)
Number of outputs
AWG70001A 4
AWG70002A 8
Impedance 50 Ω
Output voltage
High 3.3 V into 50 Ω
Low 0 V
Specifications
28 AWG70000A Series Installation and Safety Instructions
