Tektronix DPO70000 Series Technical Reference

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 3-3: Test record (cont.)
Instrument performanc e test Minimum Incoming Outgo ing Maximum
MSO70804 and DSA/DPO70804B, BWE off
10 mV, rms
N/A
__________ __________
1.462 ps
10 mV, pk-pk
N/A
__________ __________
14.62 ps
50 mV, rms
N/A
__________ __________
1.295 ps
50 mV, pk-pk
N/A
__________ __________
12.95 ps
100 mV, rms
N/A
__________ __________
1.336 ps
100 mV, pk-pk
N/A
__________ __________
13.36 ps
MSO70604 and DPO70604B, BWE off
10 mV, rms
N/A
__________ __________
1.625 ps
10 mV, pk-pk
N/A
__________ __________
16.25 ps
50 mV, rms
N/A
__________ __________
1.427 ps
50 mV, pk-pk
N/A
__________ __________
14.27 ps
100 mV, rms
N/A
__________ __________
1.463 ps
100 mV, pk-pk
N/A
__________ __________
14.63 ps
MSO70404 and DPO70404B, BWE off
10 mV, rms
N/A
__________ __________
2.022 ps
10 mV, pk-pk
N/A
__________ __________
20.22 ps
50 mV, rms
N/A
__________ __________
1.762 ps
50 mV, pk-pk
N/A
__________ __________
17.62 ps
100 mV, rms
N/A
__________ __________
1.821 ps
100 mV, pk-pk
N/A
__________ __________
18.21 ps
BWE on
MSO72004C and DPO72004C, 20 GHz
50 mV, rms
N/A
__________ __________
1.260 ps
50 mV, pk-pk
N/A
__________ __________
12.60 ps
100 mV, rms
N/A
__________ __________
1.432 ps
100 mV, pk-pk
N/A
__________ __________
14.32 ps
MSO72004C and DPO72004C, 18 GHz
10 mV, rms
N/A
__________ __________
1.336 ps
10 mV, pk-pk
N/A
__________ __________
13.36 ps
50 mV, rms
N/A
__________ __________
1.182 ps
50 mV, pk-pk
N/A
__________ __________
11.82 ps
100 mV, rms
N/A
__________ __________
1.234 ps
100 mV, pk-pk
N/A
__________ __________
12.34 ps
3–38 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
