Specifications (MSO/DPO5000 Series)
Table 2-6: Disp
lay specifications
Characteristic Description
Display type
Display area: 210.4 mm (8.28 in) (H) x 157.8 mm (6.21 in) (V), 264 mm (10.4 in) diagonal,
6-bit RGB full color, XGA (1024 x 768) TFT liquid crystal display (LCD).
Display resolution
1024 X 768 XGA display resolution
Luminance, Typical
400 cd/m
2
Waveform display color scale The TFT display can s upport u p to 262,144 colors. A subset of these colors are used for the
oscillosc
ope display, all of which are fixed colors and not changeable by the user.
Table 2 -7: Input/Output port specifications
Characteristic Description
Ethernet interface Standard on all models: 10/100/1000 Mbps
GPIB interface Available as an optional accessory that connects to the USB Device and USB Host ports
with the TEK-USB -488 GPIB to USB Adapter
The control interface is incorporated into the instrument user interface.
Video signal output
A 15 pin D-sub, VGA-type connector, supporting a minimum resolution range of 640X480
to 1280X1024.
USB interface 1 USB device connector ( 2.0 Full Speed), on the instrument rear panel.
6 USB host connectors (2.0 HS), two on the instrument front and four on the rear.
Output voltage 0 V to 2.5 V ±1% behind 1 kΩ ±2%
Probe compensator output voltage
and frequency, typical
Frequency
1 kHz ±25%
You can set the Auxiliary output to Trigger Out or Reference Clock Out.
Reference Clock Out: Outputs the 10 MHz oscilloscope reference clock.
Trigger Out: A HIGH to LOW transition indicates that the trigger occurred.
Trigger output logic levels
Characteristic
Limits
Vout (HI)
≥2.5 V open circuit
≥1.0Vintoa50Ω load to ground
Auxiliary output (AUX OUT)
Trigger Out or
Ref
erence C lock Out
Vout (LO) ≤0.7 V into a l oad of ≤4mA
≤0.25 V into a 50 Ω load to ground
External Reference nominal input
frequency
10 MHz
You must select either the internal reference (default) or 10 MHz external.
External Reference input frequency
variation tolerance
9.9 MHz to 10.1 MHz
You must run SPC whenever the external reference is more than 0.2% (2000 ppm) different
than the nominal reference frequency or reference at which SPC was last run. (See
page 4-26, Self Test.) The time base changes in correspondence to the fluctuations in the
external reference.
External Reference input sensitivity Vin 1.5V
p-p
for input frequencies between 9.9 MHz and 10.1 M Hz
External Reference input maximum
input signal
7V
p-p
External Reference input impedance Rin = 1.5 kΩ ±20%inparallelwith15pF±5pFat10MHz
2–16 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
