Tektronix DPO70000 Series Technical Reference

Specifications (MSO/DPO5000 Series)
Table 2-11: Mec
hanical specifications
Characteristic Description
Dimensions
Benchtop configuration (oscilloscope only)
Height:
9.3 in (236 mm
) Feet folded in, handle folded down
9.8 in (249 mm) Feet Folded out, handle folded down
13.5 in (343 mm) Feet Folded in, handle folded up
14.0 in (356
mm) Feet Folded out, handle folded up
Width:
17.3 in (439 mm) from handle hub to handle hub.
Depth:
8.0 in (203 mm) from back of feet to front of knobs.
8.9 in (226 mm) from back of feet to front of front cover
8.5in(216
mm) from handle back to front of knobs.
Box Dimensions:
Height: 19
.6 in (498 mm)
Width: 18.0 in (457 mm)
Length: 22.6 in (574 mm)
Rackmoun
tconfiguration (5U Rack Sizes)
Height: 8.6 in ( 218 mm)
Width: 19.2 in (488 mm) from outside of handle to outside of handle.
Depth: 1
5.1 in (384 mm) from outside of handle to back of slide.
Weight
14.9 lbs
(6.8 kg), standalone instrument, without front cover
22.2 lbs (10.0 kg), instrument with rackmount, without front cover
27.5 lbs (12.5kg), when packaged for domestic shipment, without rackmount
Clearance R equirements Top: 0 in (0 mm)
Botto
m:0in(0mm),onfeet,withflip stands down
Left side: 2 in (50.8 mm)
Right side: 0 in (0 mm)
Rear:
2in(50.8mm)
Cool
ing
Fan-
forced air circulation with no air filter.
Cons
truction m aterial
Chas
sis parts are constructed of aluminum alloy, front panel is constructed of plastic
laminate, circuit boards are constructed of glass laminate.
2–18 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
