Performance Verification (MSO/DPO5000 Series)
This chapter contains performance verification procedures for the specifications
marked with the
symbol. The following equipment, or a suitable equivalent, is
required to c
omplete these procedures.
Table 4-1: Required equipment
Description Minimum requirements Examples
DC voltage source 3 mV to 4 V, ±0.1% accuracy
Leveled sine wave generator
50 kHz to 1000 MHz, ±4% amplitude accuracy
Time mark generator 80 ms period, ±1 ppm accuracy, rise time
<50 ns
Fluke 9500 Oscilloscope Calibrator with a
9510 Output Module
Logic Probe
(MSO5000 Series only)
Low capacitance digital probe, 16 channels.
P6616 probe; standard accessory for
MSO5000 Series oscilloscopes.
BNC-to-0.1 inch pin adapter to
connect the logic probe to the signal
source.
(MSO5000 Series only)
BNC-to-0.1 inch pin adapter; female BNC to
2x16 .01 inch pin headers.
Tektronix adapter part number
679-6240-00; to connect the Fluke
9500 to the P6616 probe.
Digital Multimeter (DMM) 0.1% accuracy or better
One 50 Ω terminator Impedance 50 Ω; connectors: female BNC
input, male BNC output
Tektronix part number 011-0049-02
One 50 Ω BNC cable
Male-to-male connectors Tektronix part number 012-0057-01
Optical Mouse USB, PS2
Tektronix part number 119-7054-00;
standard accessory for MSO5000 Series
and DPO5000 Series oscilloscopes.
You might need additional cables and adapters, depending on the actual test
equipment you use.
These procedures cover all MSO5000 series and DPO5000 series models.
Disregard checks that do not apply to the specific model you are testing.
Print the test record on the following pages and use it to record the performance
test results for your oscilloscope.
NOTE. Completion o f the performance verification procedure does not update
the stored time and date of the latest successful adjustment. The date and time
are updated only when the adjustment procedures in the service manual are
successfully completed.
The performance verification procedures verify the performance of your
instrument. They do not adjust your instrument. If your instrument fails any of
the p erformance verification tests, you should return the instrument to Tektronix
for adjustment or repair.
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 4–1
