Tektronix DPO70000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C
Series, and DPO7000 Series)
This chapter contains the specifications for the instrument. All specifications are
guaranteed unless labeled "typical." Typical specifications are provided for your
convenience but are not guaranteed. Specifications that are marked with the
symbol are checked in this manual. All specifications apply to all models unless
noted othe
rwise.
≥ 4 GHz models spec ifications apply to MSO70000, MSO70000C, DSA70000B,
DSA70000C
, DPO70000B, and DPO70000C Series instruments unless noted
otherwise.
< 4 GHz mod
els specifications apply to the DPO7000 Series instruments unless
noted otherwise.
To meet s
pecifications, the following conditions must be met:
The instrument must have been calibratedinanambienttemperaturebetween
18 °C an
d28°C(64°Fand82°F).
The instrument must be operating within the environmental limits. (See
page 1
-58.)
The i nstrument must be powered from a source that meets the specifications.
(See
page 2-17.)
The instrument must have been operating continuously for at least 20 minutes
wit
hin the specified operating temperature range.
You must perform the Signal Path Compensation procedure after the
20
-minute warm-up period. See the online help for instructions on how to
perform signal path compensation. If the ambient temperature changes more
than 5 °C, repeat the procedure.
Table 1-1: Channel input and vertical specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models
Characteristic Description
Number of channels
Four channels, all identical
Input connector
≥ 4 GHz models TekConnect. Power supply compatible with VPI.
< 4 GHz models BNC and VPI probe
Input coupling
≥ 4 GHz models DC 50 Ω and GND. GND coupling disconnects the input connector from all channel input
circuitry and connects a ground reference to the channel input circuitry.
< 4 GHz models DC, AC, or GND. G ND coupling approximates ground reference by measuring an unused
preamplifier input that has been connected to ground. The s ignal being measured is not
disconnected from the channel input load.
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–1
