Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)

Table 3-3: Test record (cont.)

Instrument performance test Minimum Incoming Outgoing Maximum

Baud rate limits

Serial word recognizer

Signal path 0, P attern matching 1

Trigger 1 UI before 0

Trigger on 0

Trigger 1 UI after 0

Signal path 1, P attern matching 1

Trigger 1 UI before 1

Trigger on 1

Trigger 1 UI after 1

Pass

__________

N/A

Clock recovery frequency range

Pass

__________ __________

N/A

MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 3–41

Tektronix DPO70000 Series Technical Reference
