Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
e. Check against l
imits:
Subtract the value just obtained (base level) from that obtained
previously (t
op level).
CHECK that the difference obtained is within limits as follows:
Model Limits
≥ 4 GHz models
343.2 m V to 536.8 m V
< 4 GHz m odels
985 mV to 1015 mV
Enter voltage difference on test record.
3. Disconnect the hookup: Disconnect the equipment from Ch 1.
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 3–103
