Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-1: Channel input and vertical s pecifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series
models (cont.
)
Characteri
stic
Descriptio
n
DC voltage measurement
accuracy, < 4 GHz models
DC accuracy
(in volts)
Average acquisition mode
( ≥16 averages)
±(DC Gain Accuracy × | reading -(offset - position) | + offset accuracy + 0.1 division)
Delta voltage measurement
between any two averages
of ≥16 waveforms acquired
with the same setup and
ambient conditions
±(DC Gain Accuracy × | reading | + 0.05 division)
Sample acquisition mode,
typical
±(DC Gain Accuracy × | reading -(offset - position) | + offset accuracy + 0.15 division + 0.6 mV)
±(DC Gain Accuracy × | reading | + 0.15 division + 1.2 mV)
Delta voltage measurement
between any two samples
acquired w ith the same setup
and ambient conditions,
typical
Convert offset, position and the constant offset term to volts by multiplying by the appropriate
volts/div.
Specification applies to any sample and to the High, Low, Max, Min, Mean, Cycle Mean, RMS,
and Cycle RMS measurements. Delta volts speci fi cation applies to subtractive calculations
involving two of these measurements. Delta volts specification applies to the Positive
Overshoot, Negative Overshoot, peak-peak, and amplitude measurements.
Position range ± 5 divisions
1–4 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
