Tektronix DPO70000 Series Technical Reference

Performance Verification (MSO/DPO5000 Series)
Delta Time Meas
urement Accuracy
Channel 3
MSO/DPO = 4 ns/
Div, Source freq = 240 MHz
MSO/DPO V/Di
v
Source V
pp
Test result High limit
5 mV 40 mV 120 ps
100 mV 800 mV 118 ps
500 mV 4 V 117 ps
1 V 4 V 122 ps
MSO/DPO = 40 ns/Div, Source freq = 24 MHz
1 mV 8 mV 708 ps
5 mV 40 mV 322 ps
100 mV 800 mV 236 ps
500 mV 4 V 233 ps
1 V 4 V 417 ps
MSO/DP
O = 400 ns/Div, Source freq = 2.4 MHz
1 mV 8 mV 6.99 ns
5mV 40mV 3.01ns
100 mV 800 mV 2.07 n
s
500 mV 4 V 2.03 ns
1 V 4 V 4.02 ns
MSO/DPO = 4 μs/Div, Source freq = 240 kHz
1 mV 8 mV 69.
9ns
5mV 40mV 30.1ns
100 mV 800 mV 20.7 ns
50
0mV
4V 20
.3 ns
1 V 4 V 40.2 ns
MSO/DPO = 40 μs/Div, Source freq = 24 kHz
1 mV 8 mV 699 ns
5
mV
4
0mV
3
01 ns
100 mV 800 mV 207 ns
500 mV 4 V 203 ns
1 V 4 V 402 ns
MSO/DPO = 400 μs/Div, Source freq = 2.4 kHz
1 mV 8 mV 6.99μs
5mV 40mV 3.01μs
100 mV 800 mV 2.07 μs
500 mV 4 V 2.03 μs
1 V 4 V 4.02 μs
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 4–21
