Tektronix DPO70000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-3: Trigger specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models (cont.)
Logic and state trigger, minimum
timing requirements, typical
<4 GHz models
Minimum duration of logic state: 100 ps (10 GB/s). The minimum duration of the logic p attern
includes delay mismatch between channels.
Minimum pulse width Rearm time
Logic type
100 ps (10 GB/s)
100 ps
State type
500 ps 500 ps
Time qualified logic type
300 ps 500 ps
Video-type trigger formats and field
rates,
<4 GHz models
Triggers from negative sync composite video, field 1 or field 2 for interlaced systems, any
field, specific line, or any line for interlaced or non-interlaced systems. Supported systems
include NTSC, PAL, SECAM, and HDTV 1080/24sF, 1080p/25, 1080i/50, 1080i/60, 1080p/24,
720p/60, 480p/60.
Timeout trigger, minimum timing
requirements,
≥4 GHz models
Timeout event occurs after the signal has stayed in some state the minimum amount of time.
Setup and hold times are how long before and after the timeout event the logic level must
remain valid in order to generate a trigger.
Minimum pulse
width
Minimum rearm
time
Setup time
Hold time
Timeout type N.A. 300 ps + pulse
width
N.A. N.A.
Logic qualified timeout type
N.A. 300 ps + pulse
width
50 ps 50 ps
Timeout trigger, minimum timing
requirements,
<4 GHz models
Timeout event occurs after the signal has stayed in some state the minimum amount of time.
Setup and hold times are how long before and after the timeout event the logic level must
remain valid in order to generate a trigger.
Maximum ignored
pulse width
Minimum rearm
time
Setup time
Hold time
Timeout type 300 ps 500 ps + pulse
width
N.A. N.A.
Logic qualified timeout type
300 ps 500 ps + pulse
width
200 ps 200 ps
Window trigger, minimum timing
requirements,
≥ 4 GHz models
Minimum pulse
width
Minimum rearm
time
Setup time
Hold time
Window enters 150 ps 500 ps N.A. N.A.
Window exits 500 ps 150 ps N.A. N.A.
Logic qualified window enters
150 ps 500 ps N.A. N.A.
Logic qualified window exits
500 ps 150 ps N.A. N.A.
Window inside >t N.A. 500 ps N.A. N.A.
Window outside >t N.A. 150 ps N.A. N.A.
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–45
