Cursor setups Screen cursors
Screen cursors
From the Cursor menu, select Cursor Controls, or press the front panel Cursors button.
To use
1. To use the screen cursors, click Screen in one of the cursor control windows or from the Cursors menu
highlight C
ursor Type, and then select Screen from the submenu.
2. Use the multipurpose knobs to move the cursors.
3. Use the cursor Source drop-down list boxes to s elect the waveform you want to measure.
Behavior
Use screen cursors to indicate an arbitrary X and Y position in the waveform display a rea represented by
the inte
rsection of a vertical and horizontal cursor line. Screen c ursors measure both vertical parameters
(typically volts) and horizontal parameters (typically time or frequency).
Readou
ts display measurement parameters for both cursors. Vertical readouts display voltage values for
each cursor with respect to the zero reference point and with respect to each other. Horizontal readouts
display time or frequency values for each cursor with respect to the trigger point and with respect to
each other.
The cursor readouts appear near the bottom of the graticule when a control window is open. When the
control windows are closed, the readouts appear at the bottom of the screen.
What do you want to do next?
Learn more about the Cursor controls. (see page 82)
Go t
o a step-by-step procedure for taking cursor measurements.
(see page 601)
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 81
