About Tektronix oscilloscopes Introduction
Introduction
This Tektronix oscilloscope provides the performance, simplicity, and connectivity needed for the
ever-changing electronics, computer, and communications industries. The easy-to-use interface includes a
large displa
y and a touch-screen interface on a Microsoft Windows platform.
Choose the methods o f controlling oscilloscope operations that are most convenient for you:
Customary front-panel controls
Menus and toolbar buttons
Touch screen
What do you want to do next?
Read the product description. (see page 1)
Learn about using the online help. (see page 36)
Learn about working with your oscilloscope. (see page 962)
Product description
This online help supports the following series of Tektronix Digital Phosphor oscilloscopes:
DPO70000D and DSA70000D Series
DPO70000C and DSA70000C Series
MSO70000C Series
DPO7000C Series
MSO5000 and DPO5000 Series
NOTE. The features and options that are documented in this online help are available for several
instrument mode ls. Your instrument may not have every feature discussed.
Key features
Tektronix oscilloscopes are high-performance solutions for verification, debugging, and characterization of
sophisticated electronic designs. These oscilloscopes feature exceptional s ignal acquisition performance,
operational simplicity, and open connectivity to the design environment. Classic analog-style controls, a
large display with an optional touch-sensitive screen, and graphical menus provide intuitive control. Open
access to the Windows operating system enables unprecedented customization and extensibility.
Key features include:
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 1
