Display setups Remote operation
ClickGray(MonochromeGray)todefine waveforms in shades of g ray. Areas of the waveform with
the highest sample density appear in lighter gray shades while the areas of lowest sample density
appear in dark
er gray shades.
Click Green (Monochrome Green) to define waveforms in shades of green. Areas of the waveform
with the high
est sample density appear in lighter green shades while the areas of lowest sample
density appear in darker green shades.
Click User t
o display a color that you have previously defined with the User Palette.
TIP. The Green palette simulates the display of an analog oscilloscope.
What do yo
u want to do next?
Learn about changing the overall display appearance. (see page 163)
Learn about changing the appearance of objects in the display. (see page 167)
Learn about using text with screen displays. (see page 164)
Remote operation
Remote desktop connection
You c a n find the network setup program in the Windows Start menu. Either select All Programs >
Accessories > Remote Desktop Connection, or select Programs > Accessories > Communications >
Remote Desktop Connection.
176 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
