Bus setups Select the RS-232 bus channel polarity

Select the RS-232 bus channel polarity

NOTE. The RS-232 Bus Channel Polarity option is available on instruments with option SR-COMP.

From the Bus Setup window, select the Select tab and the RS-232 Serial bus type.

To use

Scroll through the Bus list and select the RS-232 bus to conﬁgure.

Click th

e Polarity box and select the polarity from the drop-down list.

Behavior

For the Data component:

Norma

l causes the instrument to decode signals at a high level as a binary 1.

Inverted causes the instrument to decode signals at a high level as a binary 0.

What do you want to do next?

Learn more about b us setups. (see page 95)

Learn a bout bus conﬁguration. (see page 148)

Learn about digital setups. (see page 87)

132 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
