Bus setups Set up a Custom s erial bus
To use
To change the custom decoder, click the Custom Decoder arrow and select the decoder from the
cascadin
g list.
To change the input for a component, click the Input arrow and select a channel from the cascading list.
To change the voltage threshold level, click the Threshold entry box and use the keypad to e nter a
value or use the multipurpose knobs to select a voltage level.
Behavior
The in
strument changes the components and voltage threshold levels, and uses those to decode the
selected Custom bus.
What
do you want to do next?
Learn more about bus setups. (see page 95)
Learn about bus configuration. (see page 148)
Learn about digital setups. (see page 87)
Learn how to set up an I2C se rial bus. (see page 582)
Learn how to set u p an SPI serial bus. (see page 582)
L
earn how to set up a USB serial bus.
(see page 584)
Learn how to set up an RS-232 serial bus. (see page 583)
Learn how to set up a MIPI DSI1 Serial Bus (see page 584)
Learn how to set up a MIPI CSI2 Serial Bus (see page 585)
Learnhowtosetupan8B10BSerialBus(see page 111)
Learn how to set up a CAN Bus (see page 115)
Learn how to set up a MIL-1553 Bus (see page 120)
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 113
