Display setups Display control window (Objects tab)

Display control window (Objects tab)

From the Display menu, select Objects, or open the Objects tab in the Display control window.

Overview

Use the Objects tab controls to change the appearance of objects on the oscilloscope display.

For information o n the controls, click the buttons.

To use

Click the Date/Time button to show the current date and time on the graticule.

Click the Trigger T (see page 168) button to turn this display marker on and off.

What do you want to do next?

Learn about changing the overall display appearance. (see page 163)

Learn about changing the display colors. (see page 168)

Lea

rn about using text with screen displays.

(see page 164)
