About Tektronix oscilloscopes Accessing shortcut menus by right-clicking

Waveform handle

Waveform label

Horizontal re ference marker

Trigger level marker

Accessing shortcut menus by right-clicking

You can right-click to gain quick access to most common commands.

Right-click on a graticule, an object, or a readout to access their shortcut menus. The menus are dynamic;

their contents w ill vary, depending on the area or the object you right click.

You can right-click on any of the following to open a dynamic shortcut menu:

Waveform handle

Cursors

Labels

Histogram display

Masks

Templates
