Tektronix DPO7054

Install Your Ins
trument
Maximum input
voltage, ≥4 GHz models:
50 Ω <1 V
rms
for <1V
/FS settings and < 5.5 V
rms
for ≥1 V/FS settings.
CAUTION. To ensure proper cooling, keep the bottom and sides of the instrument clear of obstructions.
DPO7000 Series and DPO/DSA70000/B Series Quick Start User Manual 3
