Display a Wavefo
rm
6. To adjust the zo
omed area vertically,
select Vertical > Zoom Setup...,
click a vertical field, and then use the
multipurpose
knobs to adjust the Vertical
Position and Factor.
Quick Tips
To clear th
e zoom area, click Position Factor Reset from the Zoom Setup control window.
You can tu
rn each zoom display on and off from the Zoom Setup c ontrol window.
Push the M
ultiView Zoom button to toggle all zoom displays on and off.
To reposi
tion the zoomed area horizontally, click and drag the horizontal marker at the bottom of the zoom box.
Lock and Scroll Zoomed Waveforms
1. To use Lock and Scroll select Zoom
Setup... from either the Vertical or
Horiz/Acq menu, and then select the
Lock and Scroll tab.
2. To scroll a single zoomed area, select a
Zoom 1-4 check box, and then click an
Auto Scroll button.
DPO7000 Series and DPO/DSA70000/B Series Quick Start User Manual 69
