Tektronix DPO7054 Quick Start User Manual

Getting Acquain
tedwithYourInstrument
1. Removable hard
disk drive
2. PS-2 connector
for mouse
3. USB ports
4. Centronics Pa
rallel Port
5. RJ-45 LAN con
nector to connect to
network
6. Video port to connect a monitor
7. TekLink connector
8. GPIB port to connect to controller
NOTE. Some instruments may have
additional
audio connectors.
9. Line In connector
10. Line Out connector for speaker
11. Mic connector for microphone
12. Video port to connect a monitor for
side-by-
side display
13. COM 1 ser
ial port
14. PS-2 con
nector for keyboard
15. CTR Bass
speaker
16. Side sp
eaker out
17. Rear sp
eaker out
18. Auxili
ary output
19. Refer
ence output
20. Exter
nal reference input
≥4 GHz models
DPO7000 Series and DPO/DSA70000/B Series Quick Start User Manual 15
