Analyzing Wavef

orms

2. Choose one of the predeﬁned math

equations.

Use the following procedure to build an advanced math waveform expression.

1. Select Math > M ath Setup....

2. Click Editor.

DPO7000 Series and DPO/DSA70000/B Series Quick Start User Manual 93
