Tektronix DSA70000/B Series User Manual

Run Application
Software
Run Applicati
on Software
The Optional Application Software CD contains free five-time trials of optional application software that you can install on your
instrument. These applications provide application-speci fic measurement solutions. S ome examples are described below.
Additional packages may be available. Contact your Tektronix representative or visit our Web site at www.tektronix.com
for more information.
Use ASM Advanced Event Search and Mark to e
xamine data by highlighting im portant events and skipping the
unimportant events.
Use CP2 for mask and measurements compliance testing for ITU-T G.703 and ANSI T1.102 communications standards.
Use DDRA Memory Bus Analysis to automatically identify DDR1, LP-DDR1, DDR2, DDR3 and GDDR3 read a
nd writes.
Use DSPT Display Port C ompliance Software to validate your IC, m otherboard, and graphics card designs.
Use DVI Compliance Test Solution S oftware for DVI physical layer compliance testing.
Use ET3 to perform 10/100/1000 Base-T Ethernet compliance testing.
Use FBD RTE module for FB-DIMM compliance for ≥4 GHz models.
Use HT3 HDMI C ompliance Test Software for HDMI compliance testing.
Use IBA RTE module for InfiniBand for ≥4 GHz models.
Use J2 Disk Drive Measurement Software to measure disk drive signals according to IDEMA standards.
Use JA3 Advanced or JE3 Essentials Jitter Analysis Software to characterize timing performance. Analyze jitter on
contiguous clock cycles using single-shot acquisitions.
Use LSA Serial Analysis Software for CAN/LIN protocol triggering and analysis.
Use LT Waveform Limit Testing to compare an acquired waveform to tolerance boundaries that you set.
Use MTH Communication Mask Testing Software for mask compliance testing on ≥4 GHz models.
Use MTM Communication Mask Testing Software for mask compliance testing is available on <4 GHz models.
Use RTE Real Time Eye Measurement Software to perform serial compliance and analysis. T here are compliance
modules for many serial standards.
Use PCE RTE module for PCI-Express for ≥4 GHz models.
Use PTH, PTU or STU Serial P rotocol Trigger Software to trigger and decode 8 B/10 B data on high-speed serial or data
protocols. Protocol triggering up to 5 GS/s.
Use PTM and PTD Serial Protocol Trigger and Decode Software to simplify validation of and isolate data dependent
faults at data rates up to 1.25 Gb/s..
Use PWR Power Measurement Software to quickly measure and analyze power dissipation in power supply switching
devices and magnetic components.
Use SLA and SLE Serial Data Link Analysis to analyze serial data links.
Use SST Serial ATA and Serial Attached SCSI compliance module with option RTE.
Use USB to characteri
ze USB2.0 signals including mask testing and parametric testing (S/W only).
Use UWB and UWBE Ultra-Wideband Spectral Analysis to make quick work of WiMedia analysis.
Use VNM CAN/LIN Protocol Analysis Software for CAN and LIN testing (CAN triggering not included).
DPO7000 Series and DPO/DSA70000/B Series Quick Start User Manual 121
