Tektronix DSA70000/B Series

To Next Page

To Previous Page

Install Your Ins

trument

≥4GHzModels

1. Turn power off

2. Connect secon

d monitor.

3. Connect key

board.

4. Connect mou

se.

5. Turn inst

rument power on.

6. Turn moni

tor power on.

≥4GHzmo

dels

10 DPO7000 Series and DPO /DS A70000/B Series Quick Start User Manual
