Commands Listed in Alphabetical Order
Eye section is d
isplayed only if you have an eye-pattern or optical measurement
defined.
Group
Measurement
Syntax
MEASUrement:MEAS<x>:JITter {EYECross | MIDref}
MEASUrement:MEAS<x>:JITter ?
Arguments
EYECross causes the measurement for jitter to be taken a t the eye crossing.
MIDref causes the measurement for jitter to be taken at the m id reference
level.
Examples
MEASUREMENT:MEAS1:JITTER EYECROSS causes the jitter measurement to
be made at the eye crossing.
MEASUREMENT:MEAS2:JITTER? might return MEASUREMENT:MEAS2:JITTER
MIDREF
, indicating that Measurement 2 will measure jitter at the mid reference
level.
MEASUrement:MEAS<x>:MAXimum? (Query Only)
This query only command returns the maximum value found for the measurement
slot specified by x, which can be 1 through 8, since the last statistical reset.
Group
Measurement
Syntax
MEASUrement:MEAS<x>:MAXimu m?
Related Commands
MEASUrement:MEAS<x>:ALL?
Returns
NR3
Examples
MEASUREMENT:MEAS3:MAXIMUM? might return
MEASUREMENT:MEAS3:MAXIMUM 4.27246105395E- 003, indicating that the
maximum value for Meas 3 is 4.272 mV.
DSA/CSA/TDS8X00/B Series Programmer Manual 2-227
