Commands Listed in Alphabetical Order
pane of the Meas
urement Setup dialog box. (If tracking is enabled for Low, the
instrument automatically calculates the low value using the method set with the
command, MEASUre me nt:MEAS<x>:SOURCE<x>:HILow:METHod.)
NOTE. The SOURCE<x> SOURCE:<<x> argument specifies the
source, which can be source 1 or source 2. To set the actual waveform
(channel, reference, or math) that is assigned to source, you must use the
MEASUremen
t:MEAS<x>:SOURCE<x> WFM command. Two sources are
provided because some measurements (gain, phase) require two sources.
Group
Measurem
ent
Syntax
MEASUrement:MEAS<x>:SOUrc e<x>:HILow:TRACk:LOW:VALue <NR3>
MEASUrement:MEAS<x>:SOUrc e<x>:HILow:TRACk:LOW:VALue?
Related Commands
MEASUrement:MEAS<x>:SOUrce<x>:HILow:METHod, MEASUrement:
MEAS<x>:SOUrce<x>:HILow:TRACk:LOW:ENABle
Arguments
NR3 is the a bsolute value of the low level for the HiLow settings.
Examples
MEASUREMENT:MEAS2:SOURCE1 :HILOW:TRACK:LOW:VALUE 5. 0E-3 sets the
low value used to take Measurement 2 on the Source 1 waveform to 5 mV.
MEASUREMENT:MEAS3:SOURCE1 :HILOW:TRACK:LOW:VALUE? might
return
MEASUREMENT:MEAS3:SOURCE1 HILOW:TRACK:LOW: VALUE
1.00000000000E-002
, indicating that the low value used to take Measurement
3ontheSource1waveformis10mV.
MEASUrement:MEAS<x>:SOUrce<x>:WFM
This command sets or queries the source waveform (SOURCE1) on which the
specified single-channel measurements are taken and from which two-channel
measurements, such as delay or phase are taken. The measurement slot is specified
by x, and can be 1 through 8. This command also sets or queries the destination
waveform (SOURCE2) to which two-channel measurements are taken. If the
source is not specified (either 1 or 2), the default is SOURCE1. Optionally,
this command c an specify the timebase for the specified source or de stination
waveform. If the timebase is not specified, the default is the Ma in timebase.
2-248 DSA/CSA/TDS8X00/B Series Programmer Manual
