WFMInpre:PT_Fmt
This command sets or queries the data point format of the incoming waveform.
Group
Waveform Transfer
Syntax
WFMInpre:PT_Fmt {Y | ENV}
Related Commands
DATa:DESTination
Arguments
Y specifies a standard waveform where one ASCII or binary point is
transmitted for each point in the waveform record. Only y values are explicitly
transmitted. Absolute coordinates are given by:
X(n)=0+(XINcr*n)+XZEro
Y(n) = (YSCALE * y(n)) + YZEro
where n = 0,1,...
ENV specifies that the waveform is transmitted as min and max pairs. Absolute
coordinates are given by:
X(n) = XINcr (INT(n/2) + XZEro
Y(n(max) = YSCALE * y(n(max)) +YZEro)
Y(n(min)) = YSCALE * y(n(min)) +YZEr o)
Examples
WFMINPRE:PT_FMT ENV sets the waveform data point format to enveloped.
WFMINPRE:PT_FMT? might return WFMINPRE:PT_FMT Y, which indicates that
the data is transmitted as a standard waveform.
WFMInpre:WFMLabel
This command sets or queries the label for the incoming waveform. Sending this
command is equivalent to selecting Waveform Properties from the Utilities menu
and entering a label in the Waveform Label field.
Group
Waveform Transfer
Syntax
WFMInpre:WFMLabel <Qstring>
WFMInpre:WFMLabel?
2-358 DSA/CSA/TDS8X00/B Series Programmer Manual
